CE AC110-240V Constant Voltage LED Driver 12V 36W For LED Floor Lamp

CE AC110-240V Constant Voltage LED Driver 12V 36W For LED Floor Lamp

  • CE AC110-240V Constant Voltage LED Driver 12V 36W For LED Floor Lamp
  • CE AC110-240V Constant Voltage LED Driver 12V 36W For LED Floor Lamp
  • CE AC110-240V Constant Voltage LED Driver 12V 36W For LED Floor Lamp
  • CE AC110-240V Constant Voltage LED Driver 12V 36W For LED Floor Lamp
CE AC110-240V Constant Voltage LED Driver 12V 36W For LED Floor Lamp
تفاصيل المنتج:
Place of Origin: China
اسم العلامة التجارية: VOTOO
إصدار الشهادات: CE,ROHS
Model Number: VP-1203000LED
شروط الدفع والشحن:
Minimum Order Quantity: 100pcs
الأسعار: negotiation
Packaging Details: white box
Delivery Time: 5-10 days
Payment Terms: Ex works
Supply Ability: 1, 000, 000PCS/week
اتصل
مفصلة وصف المنتج
تسليط الضوء:

led driver transformer, constant current led driver

,

constant current led driver

CE AC110-240V Constant Voltage LED Driver 12V 36W For LED Floor Lamp



Quick Detail:



  1. led driver 24v 1.25a

  2.  Humidity: 5% to 95% Non-Condensing

  3. Material: ABS+PC

  4.  Efficiency:85%Min

  5. 100% burn-in before shipping

  6. Constant Voltage design

  7. Certificate: CE & RoHS

  8.  Safety :SCP OCP OVP

  9. Warranty: 1 year

  10. Application: Spot light, ceiling light, down light, etc.





Features:



Input Voltage: AC110-240V

Output Voltage: DC12V

Output Current: 3000mA

Output Watt: 36W

Product Dimension: 145.0 x45.0 x 29.0mm



o Small volume, light weight, high efficiency.

o Cooling by free air convection.

o 100% Full load burn-in test.

o One year warranty.

o Ripple & Noise: 1% of Output Voltage

o Leakage Current: 0.25mA

o No load power Consumption

o Working Temperature:0-40°C Max

o Efficiency:85%Min

o High Efficiency

o Short Circuit Protection

o Over Voltage Protection

o Over Current Protection

o Green Circuit Design

o Accurate information and descriptions.

o All orders are shipped on time.

o All items are fully inspected prior to shipping to meet international standards by our QC staffs.

o All items are with CE RoHS approval to ensure the products quality.

 o Accurate information and descriptions.



Weight: 140g

o Dimensions: 145.0 x45.0 x 29.0mm





Specification:





Electrical specifications

Output Voltage

12V

Output Current

3000mA

Rated Output Power

36W

Input Voltage

100-240V

Frequency Range

50~60HZ

Typical Efficiency

85% Min

Environmental specifications

Storage temperature

-40~60°c

Operating temperature

-25~40°c

Working environment

Indoor installations

Features

Overload Protection

automatic recovery

Over Current Protection

recovers automatically after fault condition is removed

Over Temperature Protection

recovers automatically after temperature goes down

Short Circuit Protection

Hiccup mode, recovers automatically after fault condition is removed

Others

Application

LED Lighting

LED Sign Applications

   Standard

CE

RoHS

MTBF

50,000 HRS min

































































How to Install?



  1. Connect power supply to the supplied unit.
  2. Power supply must be connected to a working electrical AC line with a voltage of 100-240V.
  3. Do not install power supply in locations with high humidity, dust or strong direct sunlight.
  4. The power supply should be installed in a location with good airflow.
  5. Power supply can only be installed indoors.





Applications:



LED strip light 3528 5050, ceiling light, wall light, panel light, tube light, spotlight, plug-in light, LED tube etc.

CE AC110-240V Constant Voltage LED Driver 12V 36W For LED Floor Lamp 0



Shipping terms



1.FCL - Full Container Loading



2.LCL - Less Container Loading



3.EXPRESS



4.Air Shipment



Payment terms



1.T/T



2.L/C



3.PayPal



4.West Union
